Carbon shell with two approvals.
FIA homologation and road registration in one shell
The Podium CF is a carbon fibre shell that holds an FIA homologation and a road approval at the same time, which is what allows it to be retrofitted to a registered car. The pad concept works in different thicknesses, so the same shell is adjusted to the driver rather than the other way round. Sizes M and L. Tested and recommended by AGR (Aktion Gesunder Rücken) and the German association of back schools.
Product photography shows optional equipment.
Top features
Product
highlights
- ABE/TÜV component certification
- Competition Seat (FIA 8855-1999)
- Suitable for 3- and 4-point belts, street use
- 5 years FIA homologation
- Suitable for 4-, 5-, 6-point belts, racing use
- Seat shell in carbon (CFRP)
- Suitable for HANS systems
- Passive seat air conditioning
Key numbers
Standard, option,
accessory
| Use | |
|---|---|
| For GT vehicles / sports cars | ● |
| For touring vehicles | ● |
| Comfort | |
| Passive Seat Air Conditioning | ● |
| Pad Kit M, replaceable pads for drivers of medium build | ● |
| Pad Kit L, replaceable pads for drivers of large build | ● |
| Lightweight | |
| Composite materials | ● |
| Seat shell made of carbon (CFRP) | ● |
| Weight: complete shell incl. foam and upholstery, without sidemount | ● |
| Performance | |
| Integrated headrest | ● |
| Special lateral support in the backrest area | ● |
| Special lateral support in the seat cushion area | ● |
| Specially formed shoulder support | ● |
| Dynamic ride performance | ● |
| Slim design | ● |
| Suitable for 4-point belt (street use) | ● |
| Safety | |
| Universal side airbag, in development | ○ |
| FIA approval for 5 years | ● |
| Suitable for 3-, 4-point belt (street use) | ● |
| Suitable for HANS systems | ● |
| Competition Seat (FIA 8855-1999) | ● |
| Highly fire-resistant upholstery | ● |
| Suitable for 4-, 5-, 6-point belt (racing use) | ● |
| ABE/TÜV component certification | ● |
Comfort dimensions
in millimetres
Comfort dimensions in mm, all figures ±10 mm. Values apply to sizes M and L.
| Package | ||
|---|---|---|
| A | Seat depth | 748 mm |
| B | Seat height | 877 mm |
| C | Shell outer width at shoulder | 526 mm |
| D | Shell outer width at seat surface | 495 mm |
| G | Track width, mounting width for racing shells | 406 mm |
| Comfort | ||
| H | Seat width at the hip, Podium M | 358 mm |
| H | Seat width at the hip, Podium L | 378 mm |
| I | Shoulder support height | 544 mm |
| J | Seat depth | 438 mm |
| K | Seat height | 878 mm |
| Belt routing | ||
| L | Belt aperture height | 74 mm |
| M | Belt aperture centre | 611 mm |
| Weight | ||
|---|---|---|
| Podium M, shell total weight | approx. 7.1 kg | |
| Podium L, shell total weight | approx. 6.9 kg | |
| Net weight of the shell | approx. 4.9 kg | |
| Accessories, ordered separately | ||
|---|---|---|
| FIA adapter | 2.6 kg | |
| Pad-Kit M/L, Perlon velour black | ||
| Pad-Kit M/L, Alcantara black / leather red | ||
| Pad-Kit M/L, Alcantara red / leather black | ||
Options offered
for this shell
RECARO builds the Podium CF in the upholsteries below. In stock at ATOMIC: Perlon velour black.
Turn the seat
The viewer runs on a turntable sequence: 36 frames at 10° steps,
2000 px wide, white background, fixed camera height. Drop them into
assets/360/podium/frame-01.jpg and set data-frames="36".
The RECARO site carries a 3D viewer for this shell. That viewer is proprietary and cannot be reused, so the equivalent here runs on a frame sequence shot in-house. Drag or use the arrow keys once the frames are in place.
Until then the gallery above carries the product render, the vehicle interior and every upholstery variant.
Podium CF
Can a Podium CF be fitted to a registered road car?
Yes. The shell holds an ABE/TÜV component certification alongside the FIA homologation, which is what allows retrofitting to a road vehicle. The certification applies in combination with a RECARO console and adapter.
What is the difference between size M and size L?
Seat width at the hip: 358 mm for the M, 378 mm for the L. Pad kits in both sizes let the same shell be adjusted further.
Does it work with a HANS device?
Yes. The shell is listed as suitable for HANS systems and for 4-, 5- and 6-point harnesses in racing use.
